S CLASS™ 2 cutter User’s Manual
Detailed Operation 4-10
4.3.1.9 General
Media sensor:
The Media sensors detect whether media is loaded and also detect the end of the media. The
sensors prevent damage to the cutting strip and knife tip. The sensors can be activated or
deactivated with this menu.
When the sensors are activated, the cutter searches for the front end of the media during the
loading procedure. If it does not find it after returning the media for 1m (+/- 3 feet), it stops
returning the media and sets the origin in the X-axis.
The cutter will also stop during the loading procedure or while it is cutting if the rear sensor
detects the end of the media.
The cutter does not search for the front end of the media and assumes that the loaded media
is endless if the sensors are not activated.
Press the media sensor button, then select to activate (ON) or deactivate (OFF) both or only
the front sensor (FRONT OFF).
Press to confirm or to cancel. The default setting for the media sensors is ON.
Recut offset:
The Recut offset submenu is used to set or modify the distances between the jobs when making
multiple recuts.
Press the Recut offset button, then set it to the desired value.
Press to confirm or to cancel. The default value is 40mm.
Cut off margin:
The Cut off margin submenu is used to set or modify the distance the cutter will feed before it
will cut off the job when action ‘cut off’ is used from the software.
Press the Cut off margin and set it to the desired value.
Press to confirm or to cancel. The default value is 10mm.
Roll-up media:
The roll-up media submenu is used to choose when the cutter will start the automatic roll-up.
There are 3 possible settings. Off, after job and after AUTO-panel.
Off disables the roll-up system. After job rolls up the media after the job, regardless the number
of panels the job contains. After AUTO panel rolls up the media each time a panel is cut. The
size of the panel can be set in the Panels menu or is 100 cm when paneling is set to off.
Press the Roll-up media button and set it to the desired value.
Press to confirm or to cancel. The default value is after AUTO-panel.
The recut offset should be larger than the cut-off margin if both parameters
are used in the same job. For OPOS jobs, using the cut-off command, it is required
that the recut offset is at least 30mm bigger than the cut-off margin.
