Summa S2 SERIES - Combined Contour Cut and Cutting through

S CLASS™ 2 cutter User’s Manual
Basic Operation 2-18
6.
Press Advanced cutting.
7.
Press Panel size.
8.
Use the
arrows or
Numpad to change to
value (between 3 and 10
cm) and press Apply.
9. Press to set the cutter online again.
NOTE: The above procedure has to be done even if the software on the computer
can activate FlexCut. It is also recommended to set the FlexCut parameters on the
cutter and not with the cutting software.
FIG 2-9
2-9 COMBINED CONTOUR CUT AND CUTTING THROUGH
Settings
Back
More
Home
Tool
Tangential knife
Velocity
800 mm/s
Knife pressure
95 gr
Calibrate Knife
FlexCut
...
Advanced cutting
...
Settings | Advanced cutting
Home
Panel replot
Off
Sorting verctors
Automatic
Long verctors
0
Overcut
0.1 mm
Panelling
Off
Panel size
50 cm
Old value: 50 cm
New value: 5 cm
Range: 0 ... 250 cm
Cancel
Apply
Settings|Advanced cutting
Home
