S CLASS™ 2 cutter User’s Manual
Detailed Operation 4-13
4.3.1.11 Communication
The communication settings menu groups all the parameters that determine the method of
communicating with the computer.
Tool command:
The TOOL COMMAND option is used to determine whether the DM/PL and HP-GL tool
commands (pen select pressure and velocity) are ignored or accepted.
Press the Tool command button and activate or disable.
Press to confirm or to cancel.
USB class:
The option USB class can be set to Summa USB port 1, Summa USB port 2, Summa USB port
3, Summa USB port 4 or Printer Uni.
The Printer Uni is for using the windows printer spooler.
Because of the different USB id’s, the computer can make a distinction between several cutters
attached to it (maximum 4).
Press the USB Class button and set to the desired USB Class.
Press to confirm or to cancel. The default mode is Summa USB port 1.
LAN:
The LAN menu is explained in section 1.5.2.
NOTE: The minimum USB driver version required for attaching more than 1 cutter
to the same computer is 6.2. The change in USB class becomes active only after
The USB id in the cutting software needs to be the same as the chosen USB
id in the cutter. Each time a new USB is selected on the cutter and connected for
the first time to the computer, the wizard for installing a driver will be started by
