S CLASS™ 2 cutter User’s Manual
OPOS 3-7
OPOS origin is set to ‘Media centre’
Upon receiving an OPOS job from the computer, the cutter first sets the OPOS sensor in the
middle of the media. Then it will start searching for the OPOS XY line by slowly moving forward
the media. Once it has found the XY line, it will follow the XY line to the right until it finds the
first mark and will then start searching for the actual mark.
This setting has been created for jobs on a roll where the width of each job is at least half the
width of the media (this is usually the case; otherwise there are lots of wasted media). This
method is slightly slower than the previous method.
3.3.1.3 In combination with OPOS Barcode
The OPOS Origin is set to ‘Mark’.
This is the default setting. Upon receiving the command to start reading the barcode (from the
computer or from the touchscreen), the cutter will prompt the user to set the tool under the
barcode line. The cutter will then scan the line at two points to determine the angle of the
printed line. Then the head will go to the right pinch roller and start scanning the barcode.
The OPOS origin is set to ‘XY line’
Upon receiving the command to start reading the barcode (from the computer or from the
touchscreen), the cutter will prompt the user to set the tool under the barcode line. The cutter
will then scan the line at two points to determine the angle of the printed line. Then the sensor
will follow the barcode line till the beginning and then start scanning the barcode.
The OPOS origin is set to ‘Current Position’
Upon receiving the command to start reading the barcode (from the computer or from the
touchscreen), the cutter will immediately start searching for the OPOS barcode line by slowly
advancing the media. Once it has found the line, it will then scan the line at two points to
determine the angle of the printed line. Then the sensor will follow the barcode line till the
beginning and then start scanning the barcode.
OPOS origin is set to ‘Media centre’
Upon receiving the command to start reading the barcode (from the computer or from the
touchscreen), the cutter first sets the OPOS sensor in the middle of the media. Then it will start
searching for the OPOS barcode line by slowly moving forward the media. Once it has found
the line, it will then scan the line at two points to determine the angle of the printed line. Then
the sensor will follow the barcode line till the beginning and then start scanning the barcode.
NOTE: The OPOS Barcode workflow is explained in section 3.3.4.
