S CLASS™ 2 cutter User’s Manual
OPOS 2-5
2.1.4 Origin
1. Press .
The origin menu will appear on screen
2. Use the , , and to reposition the origin; press to
confirm or press to leave without changing the origin.
3. Press
to cut off a previous job, if necessary. The cutter will then automatically
search the front of the media and set the new origin.
Check the position of the job before cutting off. If the job was ended correctly
by the software, the distance between the new origin and the previous job is the
value of the recut distance. This should be set to a minimum of 45 mm if the cut off
button is used without moving the media first with the arrows.
2.1.5 Configuration
The S CLASS 2 cutters include 8 user configurations, all of which consist of the same
parameters. Each configuration can have unique parameter settings. This allows the cutter to
be quickly and easily reconfigured for different types of jobs or media.
NOTE: Factory default values for the different users are all set the same
way.
1. Press
The different users will appear on screen.
2. Press on the desired user or press to view more.
3. Press to confirm the new user.
4. Press to leave the menu without changing the user.
Use easy names in order to easily recognize what each user is configured to
do.
Commonly used names are: Normal, Pen, Slow, Sandblast, intermediate vinyl, etc.
NOTE: The touch screen can be used to change user configurations. User
configuration names can only be modified with Summa Cutter Control (PC only).
