6.2.3 Knife, pen and pouncing tool
The S CLASS 2 cutter comes equipped with all the tools necessary to start working
immediately.
Some tools are pre-installed, while others are packaged in separate boxes.
Below is a table that specifies which tools are delivered with the cutter. Please make sure that
all tools are included with the cutter.
Medium Drag Tangential
Standard drag knife Standard vinyl 2 1
Sandblast drag knife (requires
sandblast knife holder)
Sandblast and thicker soft
materials max 0.8mm
x x
Standard tangential knife Standard vinyl x 2
Sandblast tangential knife (requires
special sandblast nose piece)
Sandblast and thicker soft
materials max 1.2 mm
x 1
Ball point pen (requires ballpoint
penholder)
Paper x 1
Pouncing pin Paper x 1
Razor blade for cut sheet
Standard vinyl up to 0.25mm
(0.03”) thick
2 2
FIG 6-3
6-3 S CLASS 2 TOOLS
To order replacement knives, pens and/or pouncing tools, contact your local Summa dealer,
quoting the part numbers listed in table 6-8 to 6-10.
NOTE:
The S CLASS 2 cutters will only perform according to specifications if a
genuine Summa knife, pen or pouncing tool is installed. Do not replace the
standard knife, pen or pouncing tool with products from other manufacturers.
