S CLASS™ 2 cutter User’s Manual
Setup 1-19
1.6.2 Pinch roller pressure setting
The S CLASS 2 cutters are equipped with selectable pinch roller pressure. The pressure can
be set to “standard” or “low.” The change in pressure should only be done when the pinch
rollers are in the down position. When reduced pressure is needed, it is advised to set autoload
to ‘ASK’. Then the cutter will not start to load the vinyl when the pinch rollers are set down or
when the cutter is switched on. A message will appear on the touch screen, giving the user
time to change the pressure on the pinch rollers.
NOTE: Each time the pinch rollers are raised, the pressure is automatically reset
to full pressure.
FIG 1-16
1-16 REDUCING PRESSURE
To work with reduced pressure, do the following:
1. Set AUTOLOAD to ASK (see the section on Autoload:).
2. Load the media in the cutter (see the section on Media load procedure).
3. Push the lever of the two outer pinch rollers upwards and inwards (toward the machine) –
see figure above.
