S CLASS™ 2 cutter User’s Manual
OPOS 3-6
3.3.1 OPOS origin
The parameter OPOS origin is created to automate the start of the OPOS procedure. This
parameter has 4 settings (Mark, Current Position, XY Line or Media centre). The usage of this
parameter depends on the chosen OPOS mode.
This parameter is ignored when OPOS Sheet mode is activated.
3.3.1.1 In combination with OPOS X mode
The OPOS Origin is set to ‘Mark’.
This is the default setting. Upon receiving an OPOS job from the computer, the cutter will
prompt the user to set the tool above the first mark and press Apply. The cutter will then start
searching for the OPOS mark around that position.
The OPOS Origin is set to ‘Current position’.
Upon receiving an OPOS job from the computer, the cutter will immediately start looking for
the mark when it receives an OPOS job from the computer, without waiting for the user to move
the tool. Therefore, the user will have to set the tool above the first mark while loading the
material.
NOTE: If the OPOS origin is set to either ‘XY-correction line’ or ‘Center of media’,
then the cutter will react as if the parameter was set to ‘Mark’.
3.3.1.2 In combination with OPOS XY, OPOS XY2 or OPOS Xtra mode
The OPOS Origin is set to ‘Mark’.
This is the default setting. Upon receiving an OPOS job from the computer, the cutter will
prompt the user to set the tool above the first mark and press Apply. The cutter will then start
searching for the OPOS mark around that position.
The OPOS origin is set to ‘XY line’
Upon receiving an OPOS job from the computer, the cutter will prompt the user to set the tool
under the OPOS XY line and press Apply. The cutter will then start searching for the OPOS XY
line by slowly moving forward the media. Once it has found the OPOS XY line, it will follow this
line to the right until it finds the first mark and will then start searching for the actual mark.
The OPOS origin is set to ‘Current Position’
Upon receiving an OPOS job from the computer, the cutter will immediately start searching for
the OPOS XY line by slowly advancing the media. Once it has found the OPOS XY line, it will
follow this line to the right until it finds the first mark and will then start searching for the
actual first mark. Therefore, the user will have to set the origin under the OPOS XY line,
immediately after the media has been loaded.
This setting was created for jobs that are aligned at the left side and differ a lot in size on the
roll. The origin/tool can then be set to the left of the media, under the OPOS XY line to be able
to find the origin mark, even if it is situated far from the right side of the media.
