S CLASS™ 2 cutter User’s Manual
Setup 1-6
4. Media drive sleeves: The media drive sleeves only move the media when the pinch rollers
are in the “down” position. The following table lists the number of sleeves installed on each
model of the S CLASS 2 cutters.
Number of sleeves S75 (T) S120 (T) S140 (T) S160 (T)
Short sleeve 4 7 8 9
Long sleeve 1 1 1 1
5. Tool carriage: The tool carriage is the carriage for the knife holder, pen or pouncing tool.
It also holds the Optical POSitioning sensor (OPOS) and a cut-off knife to cut a sheet from
the roll when a job is finished.
6. Cutting strip: A self-healing orange strip helps avoid any damage to the knife tip when no
media has been loaded. Since cutting is done on the cutting strip, it is essential that the
strip remains intact.
7. Pouncing strip: An extra black strip to pounce on.
8. Tool holder: The left end cap has a rim so it can be used for tool storage.
9. Screws to secure the cutter base: Make sure all three screws are secured at each side
before the cutter is used.
10. Media basket: The stand and linen media basket come standard with all S CLASS 2 cutters.
