S CLASS™ 2 cutter User’s Manual
Basic Operation 2-12
However, if the test cut resembles the pattern below, increase the value of the lateral
parameter to correct the closing cut lines.
Longitudinal correction
Weed (remove) out the rectangle and, if you obtained a pattern like the one below, decrease
the value of the longitudinal parameter to correct the closing cut lines.
However, if the test cut resembles the pattern below, increase the value of the longitudinal
parameter to correct the closing cut lines.
Each time a parameter is changed, press to perform the internal knife calibration test.
NOTE: Failing to set the knife parameters correctly will result in poor cut quality.
