Chapter 8 Removing and Installing Subassemblies 83
FIGURE 8-25 Fan DC Power Connector
SCSI Backplane
To remove and install the SCSI backplane, proceed as follows.
Fan assembly
Fan
connector
DC power
connector
Front
Right side
Note: Cable restraints and SCSI data
cables are not illustrated.
