Chapter 9 Storage Devices 131
FIGURE 9-13 Removing the Diskette Drive
FIGURE 9-14 Installing Grommets and Setting the Diskette Drive Switch
Diskette
drive
Diskette drive
power cable
Diskette drive
data cable
Diskette drive
mounts
Diskette drive
switch
Grommet (4)
Screw (4)
