Chapter 11 System Board and Component Replacement 149
FIGURE 11-7 Removing a Double-Wide MBus Module
Installing a Double-Wide MBus Module
Caution – Use proper ESD grounding techniques when handling components. Wear
an antistatic wrist strap and use an ESD-protected mat. Store ESD-sensitive
components in antistatic bags before placing it on any surface.
1. Unlock the MBus module retainers and the SBus card retainers (
FIGURE 11-8).
Back panel
MBus module
(double-wide)
Hot surface
