205

APPENDIX

System Board Connector Pinouts

This appendix provides signal descriptions for the SPARCStation 20 system unit

back panel connectors.

TABLE C-1 through TABLE C-8 lists connector pin assignments

and signal descriptions. An illustration of each connector is also provided.

Parallel Connector

TABLE C-1 lists connector pin assignments and signal descriptions for the parallel

connector.

FIGURE C-1 Parallel Connector

Parallel (Top)
