Sun Microsystems SPARCstation 20 - FIGURE 8-1 Attaching a Wrist Strap to Back Panel and Removing the Power Supply

Chapter 8 Removing and Installing Subassemblies 57
FIGURE 8-1 Attaching a Wrist Strap to Back Panel and Removing the Power Supply
5. Disconnect the DC power harness from the rear of the power supply (FIGURE 8-2).
6. Set the power supply aside.
Drive bracket
Captive
screw (2)
Power
supply
DC power
connector
Power supply
rear view
DC power
harness
Wriststrap
System unit backplane metal edge
