188 SPARCstation 20 Service Manual • July 1996
FIGURE 12-3 Major Components of the System Board
SBus card
MBus module
DSIMM module
VSIMM or
NVSIMM module
Clock speed
jumper
Serial port
jumpers
OpenBoot PROM
NVRAM/TOD
AVB
Note: NVRAM/TOD carrier not illustrated.
