Chapter 11 System Board and Component Replacement 177
FIGURE 11-42 Connecting Diskette, SCSI, DC Power, and Speaker/LED Connectors
OpenBoot PROM
To remove and install an OpenBoot PROM, proceed as follows.
Note – It is not necessary to transfer the OpenBoot PROM from an existing system
board to a replacement system board.
Speaker/LED connector
SCSI
DC power
connector
connector
Diskette
connector
(optional)
