Appendix A Product Specifications 193
Maximum VA rating 290 VA
Maximum power consumption 200 W
Heat output 410 BTUs/hr
TABLE A-4 Electrical Specifications (20-inch Monitor)
Parameter Specification
Nominal frequencies 50 Hz or 60 Hz (nominal)
Nominal voltage range 100 to 120 VAC or 200 to 240 VAC
Typical operating current 1.7 A at 110 VAC, 0.85 A at 220 VAC
Standby power 5 W
Typical operating power 125 W
Maximum current 2.2 A at 100 to 120 VAC,
1.4 A at 200 to 240 VAC
Maximum VA rating 295 VA
Maximum power consumption 150 W
Heat output 427 BTUs/hr
TABLE A-3 Electrical Specifications (17-inch Monitor) (Continued)
Parameter Specification
