LUBRICATION SYSTEM 11-7
• Install the oil pump No.2 outer rotor

8.
• Apply engine oil to the outer rotor and inner rotor.
• Install the oil pump and tighten the oil pump mounting bolts to
the specified torque.
% Oil pump mounting bolt: 6 N·m (0.6 kgf-m, 4.5 lb-ft)
• Install the oil pump idle gear

9, washer and snap ring.
" 09900-06107: Snap ring pliers
• Install the primary drive gear. (!10-17)
• Install the magneto cover. (! 14-14)
• Install the clutch assembly. (!7-8, -9)
• Install the right crankcase cover and kick starter lever.
(!8-5 to -8)
• Install the brake pedal. (!16-18)
INSPECTION AFTER INSTALLATION
• Engine oil level and oil leakage (!2-11)
• Engine coolant level and coolant leakage (!2-15, -16)
• Oil pressure (! 2-37)
CAUTION
Face the punch mark

E on outer rotor

8 to the crank-
case.
CAUTION
Replace the snap ring with a new one.
