Suzuki RM-Z250 Owner's Service Manual

FRONT AND REAR WHEELS 15-7
REAR WHEEL
REMOVAL
• Loosen the rear axle nut

1.
• Place the motorcycle on a block to lift the rear wheel off the
ground.
• Remove rear axle nut

1 and washer

2.
• Remove the rear axle shaft

3 and chain adjuster washers

4.
• Disengage the drive chain

5.
• Remove the rear wheel

6.

Suzuki RM-Z250 Specifications

General

Displacement	249cc
Fuel System	Fuel injection
Bore x Stroke	77.0 mm x 53.6 mm
Ignition	Electronic (CDI)
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	coil spring, oil damped
Front Brakes	Single disc
Rear Brakes	Single disc
Front Tires	80/100-21
Rear Tires	100/90-19
Overall Width	830 mm
Ground Clearance	345 mm (13.6 in)
Seat Height	955 mm
