REAR SUSPENSION 18-13
SWINGARM
REMOVAL
• Place the motorcycle on a block to lift rear wheel off the
ground.
• Remove the rear wheel. (!15-7)
• Remove the chain guide.
• Remove the rear brake hose guide.
• Remove the rear brake caliper from the swingarm.
• Remove the cushion rod bolt and nut.
• Remove the cushion lever bolt and nut.
• Remove the swingarm pivot nut and washer.

Suzuki RM-Z250 Specifications

General

Displacement	249cc
Fuel System	Fuel injection
Bore x Stroke	77.0 mm x 53.6 mm
Ignition	Electronic (CDI)
Transmission	5-speed constant mesh
Final Drive	Chain
Front Suspension	Inverted telescopic, coil spring, oil damped
Rear Suspension	coil spring, oil damped
Front Brakes	Single disc
Rear Brakes	Single disc
Front Tires	80/100-21
Rear Tires	100/90-19
Overall Width	830 mm
Ground Clearance	345 mm (13.6 in)
Seat Height	955 mm
