14-6 ELECTRICAL SYSTEM
Step 7
1) Measure the exciter coil and charge coil peak voltages. ("14-7)
Are the peak voltages OK?
Step 8
1) Check the stator.
Is the stator OK?
Step 9
1) Measure the engine stop switch resistance. ("14-11)
Is the resistance OK?
YES Go to Step 9.
NO Go to Step 8.
YES Go to Step 9.
NO Faulty stator
YES
• Faulty CDI unit
• Open or short circuit in wire harness
NO Faulty engine stop switch
