Symmetricom TimeCreator 1000 User Manual

097-93100-01 Revision C – February, 2010 TimeCreator 1000 User’s Guide 151
Appendix A Alarms, Events and SNMP Traps
SNMP Traps
See Table A-6 below for additional trap details, such as descriptions and bindings.
The OID for alarms traps are of the format:
Alarm OID = 1.3.6.1.4.1.9070.1.2.4.1.100.2.x
where x corresponds to index values that identify specific alarms. The digits shown
for the OID Index in Table A-6 below correspond to x. See Table A-5 for listings of
the full OID for each alarm.
MTIETEXC
1.3.6.1.4.1.9070.1.2.4.1.100.2.15
trapMTIETExceed
Minor
MTIE35EXC
1.3.6.1.4.1.9070.1.2.4.1.100.2.16
trapMTIE35Exceed
Minor
PPJEXC
1.3.6.1.4.1.9070.1.2.4.1.100.2.17
trapPPJitterExceed
Minor
FEREXC
1.3.6.1.4.1.9070.1.2.4.1.100.2.18
trapFERExceed
Minor
PWRFAIL
1.3.6.1.4.1.9070.1.2.4.1.100.2.19
trapPowerFail
Major
PWRFANFAIL
1.3.6.1.4.1.9070.1.2.4.1.100.2.20
trapPowerFanFail
Major
NOIOC
1.3.6.1.4.1.9070.1.2.4.1.100.2.21
trapNoIOC
Minor
JAMSYNC
1.3.6.1.4.1.9070.1.2.4.1.100.2.22
trapJamSyncRequired
Minor
DCMUNLOCK
1.3.6.1.4.1.9070.1.2.4.1.100.2.23
trapDCMUnlocked
Major
PLLUNLOCK
1.3.6.1.4.1.9070.1.2.4.1.100.2.24
trapPLLUnlocked
Major
Note: The ID in the Trap OID Name column in Table A-6 below is
used with the
Generate Message command to raise a specific trap:
tc1000>generate message
“id,trapAID1,trapAID2,trapState,trapValue”
If trapAID1 corresponds to the IOC module number,1 or 2, use the
value trapAID1=257 for IOC1 and trapAID2=258 for IOC2. Use the
number “0” for entries of “n/a”.
Example
To generate the message for the trap “IMC-IOC 1 communication
failed”, which has id=2, trapAID1=257 (corresponds to trapAID1=1 for
IOC1 in
Table A-6) trapAID2=0, trapState=2, and trapValue=0:
tc1000>generate message “2,257,0,2,0”
Table A-5. TimeCreator 1000 Alarm Trap Details (Continued)
Trap Name
(trapID)
OID
Trap OID
Name
Trap
Severity
