Tektronix GeoProbe G10 User Manual

G10 Hardware Maintenance Guide 7.13.2 56 
3
Blades and RTMs
Rev. 002-140228
F1-F2 (A) YELLOW Fabric Interface Activity Indicator
 YELLOW—Ethernet activity occurring.
 OFF—No Ethernet activity occurring.
B1-B2 (L) GREEN or YELLOW Base Interface Link Indicator
 GREEN = The Ethernet link is up at 1 Gb speed.
 YELLOW = The Ethernet link is up at 100M speed.
 OFF = No link established.
B1-B2 (A) YELLOW
Base Interface Activity Indicator
 YELLOW—Ethernet activity occurring.
 OFF—No Ethernet activity occurring.
U1-U4 Not used.
H/S BLUE Indicates blade state machine status and hot swap status.
During blade installation:
 SOLID BLUE—The on-board IPMC powers up.
 BLINKING BLUE—The blade communicates with shelf
manager.
 OFF—The blade is active.
During blade removal:
 SOLID BLUE—The blade is in standby mode and can be
safely extracted.
 OFF—The blade is operational, and it is unsafe to extract
it.
 BLINKING BLUE—The module is in a transition between
standby mode and operational mode.
Table 3.16 - IAP320 LED Indicators
(Continued)
LED LED Color Description
Tektronix Communications | For Licensed Users | Unauthorized Duplication and Distribution Prohibited
