2-20
Service Data
4st 25/30 2022
Description Item Standard Value
Electrical Parts
Spark Plug
Plug Type DCPR6E (NGK)
Spark Gap 0.8 - 0.9 mm (0.030 - 0.035 in)
Ignition Coil
Primary Coil Resistance їʝ
Secondary Coil Resistance
Nїʝ
NїZLWKVSDUNSOXJFDS
Magneto
(Alternator)
Alternator (MAX) 12V–210W
Power Generation Performance
1000 r/min, 14 V, 6 A or more
5000 r/min, 14 V, 15 A or more
Charge Coil Resistance (Between W-W-W Lines)
їʝ
Fuel Injector
Measuring the Resistance Between Terminals їʝ
Operating Check -
F.F. P
Wear and damage of seals and grommets -
Operating Check -
Crank Position
Sensor
Clearance with Encoder Ring (Flywheel) 0.8 mm (0.0315 in) ± 0.2 mm (0.0079 in)
Pulser Coil Resistance (Between Terminals) їʝ
T.P. S
Measuring the Resistance Between Terminals Nї
ISC Valve
Measuring the Resistance Between Terminals їʝ
Engine Temperature
Sensor
Measuring the Resistance Between Terminals
Nїʝ
Nїʝ
T- MAP Sensor
Measuring the Resistance Between Terminals
Nїʝ
Nїʝ
Rectifier
Measuring the Resistance Between Terminals Refer to the tester check table in Chapter 8.
Starter Motor
Output 12 V 0.7 kW
Brush Length 13.9 - 14.2 mm (0.5472 - 0.5591 in)
Commutator Undercut 1.0 - 1.2 mm (0.0394 - 0.0472 in)
Commutator Outer Diameter 28.2 - 28.5 (1.1102 - 1.1024 in)
Starter Solenoid
Rated Voltage 12 V (DC)
Excitation Current 4 A or less
Exciter Coil Resistance їʝ
Fuse
Capacity 20 A x 1
Power Tilt
Relief Valve
Valve Opening
Pressure
Relief Valve Opening Pressure (UP Side) 13.8 - 18.4 MPa
Relief Valve Opening Pressure (DN Side) 6.5 - 9.6 MPa
Spool Check Valve Opening Pressure:
Upper Chamber Side
0.2 MPa
Oil Capacity 263 ml
Specified Oil
Hydraulic oil of equivalent or higher standard than DEXRON
(ATF etc.)
Motor
Rated Voltage 12 V (DC)
Continuous Run 60 sec
Output 130 W
Direction of Revolution Forward / Reverse
Circuit Breaker Type Bimetal Type
Circuit Breaker Activation / Deactivation 20 sec or more at 25 A (25°C)/within 30 sec (25°C)
To Next Page
