2-21

4st 25/30 2022

Functional Limit Action To Be Taken

Clean and remove the carbon stains or damage

Replace if the electrode is worn out significantly

Spark gap 1.2 mm (0.045 in) Replace if out of standard value

- Replace if out of standard value

Replace with new part

Parts that do not make a “clicking” sound when a voltage of 12 V is

applied on the terminals

Parts that are worn out or damaged

Replace with new part

Checking the operation sound or the valve in the fuel rail section

- Re-adjust if out of standard value

- Replace if out of standard value

Replace if out of standard value

- Replace if out of standard value

9.5 mm (0.3740 in)

Replace if out of standard value

0.7 mm (0.0276 in)

28 mm (1.1024 in)

Replace if out of standard value

Burn out

Replace with new part after eliminating the cause of the disconnection
