Topcon KR-1W - Page 119

117
FUNCTION SETTING USING SETTINGS
DISPLAY (DISPLAY SETTING)
DISPLAY performs setting related to screen display.
Setting the exam
purpose at the
time of startup
Screening
Set Screening for the exam when the power is turned
on.
Screening 141
Pupillometry
Set Pupillometry for the exam when the power is
turned on.
Dry eyes
Set Dry Eye for the exam when the power is turned
on.
Cataract
Set Cataract for the exam when the power is turned
on.
Over refraction
Set Over Refraction for the exam when the power is
turned on.
Custom
Set Custom for the exam when the power is turned
on.
Set item display Setting Change button Set contents Initial value Page
Custom map
Set by special input
screen.
Layout used for screen display and printing can be
set/registered up to 4 types.
142
Change D/mm
D
Results of KRT measurement is displayed in D
(diopter).
D 144
mm
Results of KRT measurement is displayed in mm
(millimeter).
HV/R1R2
HV
Display style of KRT measurement results is set to
HV (horizontal/vertical).
R1R2 144
R1R2
Display style of KRT measurement results is set to
R1R2 (flat/steep meridian).
Placid Overlay
ON
When analysis results are initially displayed,
Placid overlay is displayed.
OFF 145
OFF
When analysis results are initially displayed,
Placid overlay is not displayed.
Pupil Overlay
ON
When analysis results are initially displayed,
pupil detection overlay is displayed.
OFF 145
OFF
When analysis results are initially displayed,
pupil detection overlay is not displayed.
Angle Scale
Overlay
ON
When analysis results are initially displayed,
Angle Scale overlay is displayed.
OFF 145
OFF
When analysis results are initially displayed,
Angle Scale overlay is not displayed.
Topo/Aberration
Map Overlay
NONE
When analysis results are initially displayed,
Topo Map overlay is not displayed.
NONE 145
Axial
When analysis results are initially displayed,
corneal axial overlay is displayed.
Instantaneous
When analysis results are initially displayed,
corneal instantaneous overlay is displayed.
Total ocular aberration
When analysis results are initially displayed,
total ocular aberration overlay is displayed.
Ocular high-order
aberration
When analysis results are initially displayed,
ocular high-order aberration overlay is displayed.
Corneal high-order
aberration
When analysis results are initially displayed,
corneal high-order aberration overlay is displayed.
Transparency of
overlay
0% No transparency of overlay.
50% 146
25% Transparency of overlay is set for 25%.
50% Transparency of overlay is set for 50%.
75% Transparency of overlay is set for 75%.
Set item display Setting Change button Set contents Initial value Page
