118
FUNCTION SETTING USING SETTINGS SCREEN
Marker Overlay
ON
When analysis results are initially displayed,
Marker overlay is displayed.
OFF 146
OFF
When analysis results are initially displayed,
Marker overlay is not displayed.
Hartmann Point
Overlay
ON
When analysis results are initially displayed,
Hartmann detection point overlay is displayed.
OFF 146
OFF
When analysis results are initially displayed,
Hartmann detection point overlay is not displayed.
Hartmann Grid
Overlay
ON
When analysis results are initially displayed,
Hartmann detection grid overlay is displayed.
OFF 146
OFF
When analysis results are initially displayed,
Hartmann detection grid overlay is not displayed.
Total Aberration
Map Range
Set by ten-key display. 0.1 m to 50.00 m (changeable with 0.01 m steps) 20 m 146
Total Aberration
Map Overlay -
Cross scale
ON
When analysis results are initially displayed, total
aberration map overlay (cross scale) is displayed.
ON 147
OFF
When analysis results are initially displayed,
total aberration map overlay (cross scale) is not
displayed.
Total Aberration
Map Overlay -
Angle Scale
ON
When analysis results are initially displayed, total
aberration map overlay (angle scale) is displayed.
ON 147
OFF
When analysis results are initially displayed,
total aberration map overlay (angle scale) is not
displayed.
Total Aberration
Map Overlay -
mm Grid Scale
ON
When analysis results are initially displayed, total
aberration map overlay (mm grid scale) is displayed.
OFF 147
OFF
When analysis results are initially displayed,
total aberration map overlay (mm grid scale) is not
displayed.
HOA, Astig. Map
Range
Set by ten-key display.
Display range (maximum and minimum values) of
color bar of high-order aberration and astigma map is
set. (changeable with 0.01
m steps)
5.00 147
HOA, Astig. Map
Overlay - Cross
Scale
ON
When analysis results are initially displayed,
overlay of high-order aberration map (cross scale) is
displayed.
ON 148
OFF
When analysis results are initially displayed,
overlay of high-order aberration map (cross scale) is
not displayed.
HOA, Astig. Map
Overlay - Angle
Scale
ON
When analysis results are initially displayed,
overlay of high-order aberration map (angle scale) is
displayed.
ON 148
OFF
When analysis results are initially displayed,
overlay of high-order aberration map (angle scale) is
not displayed.
HOA, Astig. Map
Overlay - mm
Grid Scale
ON
When analysis results are initially displayed,
overlay of high-order aberration and astigma map
(mm grid scale) is displayed.
OFF 148
OFF
When analysis results are initially displayed,
overlay of high-order aberration and astigma map
(mm grid scale) is not displayed.
TopoMap
Scale Unit
D Display unit of topo-map is set to D (diopter).
D 148
mm Display unit of topo-map is set to mm (millimeter).
TopoMap
Scale - Type
Adjustable Scale type of topo-map is set to Adjustable.
Absolute 149Normalized Scale type of topo-map is set to Normalized.
Absolute Scale type of topo-map is set to Absolute.
TopoMap Scale -
Adjustable
Center
Set by ten-key display.
Center value when the scale type of topo-map is
Adjustable is set. 30.00D to 50.00D (changeable with
0.50D steps)
47.50 149
Set item display Setting Change button Set contents Initial value Page
