Chapter 10
170
UM10372_PCNC440_Manual_0221A
diAgRAMS ANd PARTS liST
Spindle Head Assembly Parts List
ID PN Description
1 30531 M8 Flat Washer
2 33163 Spindle Assembly
3 35741 Spindle Head
4 35742 Spindle Motor Mount
5 35743 Motor Pivot Plate
6 35744 Spindle Motor Pulley
7 35745 Pulley Washer
8 35746 Spindle Lock Block
9 35747 Spindle Lock
10 35748 Door Jamb
11 35749 Jamb Bushing
12 35750 Spindle Motor Cover
13 37312 Spindle Cover Latch
14 35751 Motor Cover Door
15 35422 Spindle Motor
16 35753 Spindle Lock Spring
17 35754 M6 x 30 mm Socket Head Cap Screw
18 35755 Lock Washer
19 35756 Spindle Motor Pulley Bushing
20 35757 Spindle Motor Key
21 35758 M5 x 10 mm Dowel
22 35759 Plasc Washer
23 35760 M8 x 25 mm Socket Head Cap Screw
24 35761 M8 x 45 mm Socket Head Cap Screw
25 35762 M12 x 35 mm Socket Head Cap Screw
26 35763 M8 Hex Nut
27 35764 M12 Flat Washer
28 35765 M6 x 12 mm Phillips Head Machine Screw
29 35766 Spindle Motor Plate Bushing
30 35801 M12 x 45 mm Socket Head Cap Screw
31 35802 M12 Split Lock Washer
32 35803 M12 Flat Washer
33 35804 M8 x 40 mm Pull Dowel
34 33014 Drawbar
35 33168 Drawbar Bushing
36 35799 Spindle Belt (Gates # 170J-4)
