Tormach PCNC 440 - 1.1 Specifications

Chapter 1
20
UM10372_PCNC440_Manual_0221A
OvERviEw
1.1 Specifications
Mechanical
Key
Dimensions
(machine table)
Length 18”
Width 6.25”
T-Slot Width 10 mm
T-Slot Center-to-Center Distance 50 mm
Number of Standard T-Slots Three along X-axis
Maximum Weight on Table 150 lbs.
Spindle Nose to Table (~max) 12”
Spindle Nose to Table (~min) 2”
Spindle Center to Z-axis Way Cover 6.5”
Travels
X-axis 10”
Y-axis 6.25”
Z-axis 10”
Spindle
Speed Range 300-10,000 RPM
Maximum Rang 3/4 hp (600 W)
Drive System
Belt Driven (two
posions)
Low Belt: 300-4500 RPM
High Belt: 650-10,000 RPM
Taper R8
Feed Rates
Rapids on X 135 IPM
Rapids on Y 135 IPM
Rapids on Z 110 IPM
Max Cung 135 IPM (X, Y), 110 IPM (Z)
Temperature Operang Range 45˚F-100˚F (7˚C-38˚C)
Electrical
Power Requirements 115 VAC
Recommended Circuit Amperage
1
15 AMP
1
Dedicated circuit recommended; do not use with a ground-fault interrupter (GFI).
