Chapter 10
172
UM10372_PCNC440_Manual_0221A
diAgRAMS ANd PARTS liST
Z-axis Column Assembly Parts List
ID PN Descripon
1 31860 Limit Switch
2 31685 M6 x 25 mm Socket Head Cap Screw
3 35755 Lock Washer
4 35760 M8 x 25 mm Socket Head Cap Screw
5 35771 M8 x 20 mm Socket Head Cap Screw
6 35772 M6 Flat Washer
7 35773 M5 x 16 mm Socket Head Cap Screw
8 35774 M5 x 10 mm Buon Head Cap Screw
9 35775 M3 x 6 mm Flat Head Cap Screw
10 35776 M10 Eyebolt
11 35777 Z-column
12 35778 Z-motor Plate
13 35779 Z-saddle
14 35780 Z-gib
15 35781 Gib Screw
16 35782 Z-axis Motor Assembly
17 35783 Z-coupling .5”-16 mm
18 35784 Z-axis 16 mm Ballscrew and Nut
19 35785 Z-ballscrew Bumper
20 35786 Z-switch Dog
21 35787 Z-column Cover
22 35788 Electrical Cabinet
23 35789 Electrical Cabinet Cover
24 35790 Z-bellows Bracket
25 35791 Z-bellows
26 35792 Z-ballnut Bracket
27 35804 M8 x 40 mm Pull Dowel
28 35805 M14 x 45 mm Socket Head Cap Screw
29 35806 M14 Flat Washer
30 35807 M14 Split Lock Washer
