Chapter 10
174
UM10372_PCNC440_Manual_0221A
diAgRAMS ANd PARTS liST
X-Y Axis Assembly Parts List
ID PN Descripon
1 31860 Limit Switch
2 30970 M8 x 55 mm Socket Head Cap Screw
3 31379 M6 Lock Washer
4 31513 M6 Flat Washer
5 31543 M6 x 25 mm Socket Head Cap Screw
6 35760 M8 x 25 mm Socket Head Cap Screw
7 35773 M5 x 16 mm Socket Head Cap Screw
8 35774 M5 x 10 mm Buon Head Cap Screw
9 35781 Gib Screw
10 35783 Coupling .5”-16 mm
11 35793 Bellows Stand O
12 35794 Y-front Bellows
13 35795 Y-rear Bellows
14 35796 M6 x 10 mm Flat Head Cap Screw
15 35797 M6 x 10 mm Buon Head Cap Screw
16 35798 M3 x 20 mm Pan Head Machine Screw
17 35808 Machine Base
18 35809 X-Y Saddle
19 35810 Machine Table
20 35811 Y-motor Mount
21 35812 X-motor Mount
22 35813 X-ballnut Bracket
23 35814 Y-ballnut Bracket
24 35815 X-gib
25 35816 Y-gib
26 35818 Y-axis 16 mm Ballscrew and Nut
27 35817 X-axis 16 mm Ballscrew and Nut
28 35819 Y-switch Plate
29 35820 Y-switch Bracket
30 35821 X-switch Bracket
31 35822 X-switch Dog
32 35823 Y-switch Dog
33 35824 X-axis Motor Assembly
34 35825 Y-switch Cover
35 35826 Front Drip Guard
36 35827 Table Tray
37 35828 Y-ballnut Shim
