Electrical Cabinet Parts List
ID PN Descripon
1 35629 48 VDC Fan
2 35621 Spindle Drive
3 33374 Control Module
4 37282 DIN Connector Assembly
5 35721 DB-25 Ribbon Cable Assembly
6 35720 Main Disconnect
7 30511 Fuse Holder
8 31659 C1 Contactor
9 37153 24 VDC Power Supply
10 37154 Coolant Relay
11 35627 Fuse 3 – 2A
12 30456 Fuse 1 – 6A
13 30455 Fuse 6 – 15A
14 37283 Fuse 10 – 10A
15 31440 EMI Filter
16 35628 48 VDC Power Supply
17 33219 Push Buon
18 35980 E-stop
— 30627 16 mm Flex Conduit
1
— 30722 12 mm Flex Conduit
2
— 30628 Connector for 16 mm Flex Conduit
— 30723 Connector for 12 mm Flex Conduit
1
16 mm ex conduit used for: X-axis motor, Y-axis motor, Z-axis motor, spindle motor, E-stop, and X-Y limit
switch
2
12 mm ex conduit used for Y-axis limit switch
