Tormach PCNC 770 - Linear Motion at Feed Rate - G01

Chapter 7
100
UM10350_PCNC770_Manual_0916A
Programming
If cuer radius compensaon is acve, the moon diers from the above; see Cuer Compensaon
later in this chapter. If G53 is programmed on the same line, the moon also diers; see Absolute
Coordinates later in this chapter. Depending on where the tool is located, there are two basic rules
to follow: If the Z value represents a cung move in the posive direcon (i.e. out of a hole), the
X axis should be moved last. If the Z value represents a move in the negave direcon, the X-axis
should be executed rst. It is an error if:
• All axis words are omied
• G10, G28, G30 or G92 appear in the same block
7.5.2 Linear Motion at Feed Rate – G01
For linear moon at feed rate (for cung or not), program: G01 X~ Y~ Z~ A~ F~
Word Denition
X~ X-axis coordinate
Y~ Y-axis coordinate
Z~ Z-axis coordinate
A~ A-axis coordinate
F~ Feed rate
This produces coordinated linear moon to the desnaon point at the current feed rate (or slower
if the mill won’t go that fast).
The axis words are oponal, except that at least one must be used. The G01 is oponal if the current
moon mode is G01. If cuer radius compensaon is acve, the moon diers from the above; see
Cuer Compensaon later in this chapter. If G53 is programmed on the same line, the moon also
diers; see Absolute Coordinates later in this chapter.
It is an error if:
• All axis words are omied
• G10, G28, G30 or G92 appear in the same block
• No F word is specied
