Chapter 8
143
UM10350_PCNC770_Manual_0916A
Accessories
8.
Accessories
This chapter describes in brie
f the opons and accessories av
ailable for the PCNC mill.
8.1
4th Axis Kits
Each PCNC
mill
is
pre-wir
ed for installaon of
an
oponal
4th
Axis
Kit.
A
varie
ty
of
4th axis
opons
are a
vailable.
Standar
d Rot
ar
y T
able 4th Axis Kits
(see
Figure 8.1
)
Mounted on le
side of table; horiz
ontal mounng also possible. A
vailable models include:
PN
Description
30289
8” T
able
30290
6”
T
able
Figure 8.1
142
144
