Chapter 11
227
UM10350_PCNC770_Manual_0916A
Diagrams and Parts List
11.7 Ribbon Cable and Miscellaneous
OUTLET COMPUTER (PN 30177)
OUTLET COMPUTER (PN 30177)
M3.5
24.6 in
24.6 in
4 empty
2 wires not connected
10 Pin IDC Connector
X-axis
26 Pin IDC Connector
PIN 1
TRIANGLE
PIN 1 is next to the triangle
J6 - STEPPER DRIVERS
(30686)
J4 - DB25 MALE
(30684)
IDC-26 30168
CABLE-26 30170
DB25 MALE 30166
IDC-16 30167 (2)
CABLE-16 30169
J3 - CONNECTION BOARD
(30685)
I/O MOUNT PLATE - 31661
OUTLET COOLANT
(PN 30177)
OUTLET COMPUTER (PN 30177)
OUTLET COMPUTER (PN 30177)
4-40 STANDOFF (PN 30211)
4-40 NUT (PN 30212)
24.6 in
24.6 in
4TH AXIS EXPANSION
On side of cabinet
10 Pin IDC Connector
A-axis
4 empty
2 wires not connected
10 Pin IDC Connector
Z-axis
10 Pin IDC Connector
Y-axis
26 Pin IDC Connector
TRIANGLE
PIN 1 is next to the triangle
Example IDC-26, IDC-16 and IDC-10
E-STOP INTERFACE PORT
On side of cabinet
M3
21.4 in
21.4 in
PIN 2
