Chapter 6
86
UM10350_PCNC770_Manual_0916A
PathPilot Interface
6.8.3 Probe/ETS Setup Tab
The Probe/ETS Setup tab is used to align and set the probe and ETS heights (see Figure 6.34). For
informaon on probe and ETS setup, refer to chapter 8, Accessories.
6.9 ADMIN Commands
Several ADMIN commands are provided for operator use.
ADMIN Command Description
ADMIN CONFIG Switch conguration
ADMIN DATE Customize controller date and time
ADMIN DISPLAY Customize controller screen display
ADMIN KEYBOARD Customize controller keyboard layout
ADMIN NETWORK WIFI network setup
ADMIN OPENDOORMAXRPM
Set spindle speed RPM with spindle door open; for use with Full
Enclosure Door Switch Kit (PN 35550)
ADMIN SETTINGS BACKUP Save tool offset and xture information backup to store externally
ADMIN SETTINGS RESTORE
Restore tool offset and xture information backup from external
location
ADMIN TOUCHSCREEN
Calibrate touch screen; for use with 17" Touch Screen Kit (PN
35575)
Figure 6.34
