Tormach PCNC 770 - Set Tool Table - G10 L11; Set Coordinate System - G10 L20

Chapter 7
107
UM10350_PCNC770_Manual_0916A
Programming
7.5.5.4 Set Tool Table – G10 L11
G10 L11 is just like G10 L10 except that instead of seng the entry according to the current osets,
it is set so that the current coordinates would become the given value if the new tool oset is
reloaded and the mill is placed in the G59.3 coordinate system without any G92 oset acve. This
allows the operator to set the G59.3 coordinate system according to a xed point on the mill, and
then use that xture to measure tools without regard to other currently acve osets.
Program: G10 L11 P~ X~ Z~ R~ I~ J~ Q~
Word Denition
P~ Tool number
R~ Radius of tool
It is an error if:
• Cuer Compensaon is on
• The P number is unspecied
• The P number is not a valid tool number from the tool table
• The P number is 0
7.5.5.5 Set Coordinate System – G10 L20
G10 L20 is similar to G10 L2 except that instead of seng the oset/entry to the given value, it is set
to a calculated value that makes the current coordinates become the given value.
Program: G10 L20 P~ X~ Y~ Z~ A~
Word Denition
P~ Number of coordinate system to use (G54 = 1, G59.3 = 9)
X~ X-axis coordinate
Y~ Y-axis coordinate
Z~ Z-axis coordinate
A~ A-axis coordinate
It is an error if:
• The P number does not evaluate to an integer in the range 0 to 9
• An axis other than X or Z is programmed
