Tormach PCNC 770 - Verify Axis Function; Coolant On;Off; Installation Troubleshooting

Chapter 3
36
UM10350_PCNC770_Manual_0916A
Installation
3.7.3 Verify Axis Function
1. Reference the mill by clicking the Ref Z, Ref X, and Ref Y buons (see Figure 3.19); the mill moves.
2. Next, switch to the Main screen.
3. Use keyboard to verify axis moon:
a. To move X-axis, use the ←/→ keys.
b. To move Y-axis, use the ↑/↓ keys.
c. To move Z-axis, use the Page Up/Page Down keys.
4. To test the oponal jog shule:
a. Press the corresponding axis buon (X, Y, or Z) to select the axis.
b. Twist shule ring of jog shule to move axis. Twist in opposite direcon to reverse direcon.
3.7.4 Coolant On/Off
The coolant pump can be controlled manually using the Coolant switch on the operator panel (see
Figure 3.14). This switch has three posions: On, O, and Auto. The Auto posion allows PathPilot
to control the coolant pump. To operate:
1. Press On to turn the coolant pump on.
2. Press O to turn the coolant pump o.
3. Press Auto to switch to operang system control of coolant.
4. In Auto mode, click the Coolant buon on the PathPilot interface to turn coolant on. Click the
buon again to turn coolant o.
3.7.5 Installation Troubleshooting
Upon inial installaon, the most likely reason for non-funconing controls is wires that have
become loose during transport. Check to ensure all wires inside the electrical cabinet are properly
connected as follows:
WARNING! Electrical Shock Hazard: Be sure to power o machine before making any electrical
modicaons. Failure to do so may result in serious injury or death.
1. Power o mill according to the Power O/On Procedure detailed earlier in this chapter.
2. Using two ngers, rmly tug each wire connecon near its terminaon point. Any loose wires
should be re-seated and re-ghtened.
NOTE: Refer to chapter 10, Troubleshoong, for more informaon on mill troubleshoong.
