3.5 Essential Controls Overview
Check to ensure your local power supply
meets the requirements detailed in chapter
2, Site Planning and Prep.
3.5.1 E-stop, Start, Reset, and Power
NOTE: Before connuing, review Power O/On
Procedure later in this secon.
E-stop (emergency stop)
Each mill has one emergency Stop buon or
E-stop pre-installed on the Operator Panel (see
Figure 3.13 and 3.14). The E-stop terminates
all moon and spindle funcon. Depress the
E-stop and it locks in the Power O posion
(see Figure 3.15). Turn the E-stop clockwise a
quarter turn to release; press the green Start
buon to power back on (see Figure 3.13).
Start
The green Start buon powers on circuits for
the axis drives. On the Operator Panel, the
Machine LED indicates the green Start buon
is pressed (see Figure 3.14). When lit, the
Machine OK LED on the PathPilot interface’s
Status tab should be solid green (see Figure
3.16), indicang the mill is powered on and
ready to operate.
NOTE: Once E-stop is depressed, Start buon is
inoperave unl the E-stop is released.
Figure 3.13
E-stop
Start
Main
Disconnect
Figure 3.14
Figure 3.15
E-stop depressed
(Power Off)
Figure 3.16
E-stop released
(Power On)
