Tormach PCNC 770 - Coolant Hose and Accessories; Tramp Oil Pillow; Spindle Options; High Speed Spindle Options

Chapter 8
148
UM10350_PCNC770_Manual_0916A
Accessories
8.4.4 Coolant Hose and Accessories
Addional coolant hose, nozzle styles, valves,
manifolds, and ngs are available to design a custom
ood-coolant system for any PCNC mill. Individual
coolant systems are also available (see Figure 8.8).
PN Description
33215 Coolant Hose Accessory Kit w/ Pliers
8.4.5 Tramp Oil Pillow
These absorbent pillows are placed inside the coolant
tank to remove excess tramp oil from the coolant system.
PN Description
31925 Floating Tramp Oil Collection Pillow
8.5 Spindle Options
8.5.1 High Speed Spindle Options
Several opons are available for high speed spindles including:
PN Description Coolant Compatible
31890 Kress Companion Spindle Kit (vertical) No
32444 Kress Companion Spindle Kit, Horizontal Adaptor —
31350 Tormach Speeder
™
Ye s
35178 High-speed Spindle Kit for PCNC 1100 Ye s
Figure 8.9
Figure 8.10
Figure 8.8
