Tormach PCNC 770 - Rapid Linear Motion - G00

Chapter 7
99
UM10350_PCNC770_Manual_0916A
Programming
Summary of G-codes
G91, G91.1 Incremental distance mode
G92 Offset coordinates and set parameters
G92.x Cancel G92 etc.
G93, G94, G95 Feed modes
G97, G97 CSS, RPM modes
G98 Initial level return / R-point level after canned cycles
In the command examples, the lde symbol (~) stands for a real value. If L~ is wrien in an example,
the ~ is oen referred to as the L number. Similarly the ~ in H~ may be called the H number, and so
on for any other leer. As described in detail elsewhere, a real value may be one of the following:
• An explicit number. For example: 4.4
• An expression. For example: [2+2.4]
• A parameter value, For example: #88
• A unary funcon value. For example: acos[0]
Many commands require axis words (X~,Y~,Z~, or A~) as an argument. Unless explicitly stated
otherwise, the following assumpons can be made:
• Axis words specify a desnaon point
• Axis words relate to the currently acve coordinate system, unless explicitly described as
being in the absolute coordinate system
• Where axis words are oponal, any omied axes retain their current value
Any items in the command examples not explicitly described as oponal are required.
7.5.1 Rapid Linear Motion – G00
For rapid linear moon, program: G00 X~ Y~ Z~ A~
Word Denition
X~ X-axis coordinate
Y~ Y-axis coordinate
Z~ Z-axis coordinate
A~ A-axis coordinate
This produces coordinated linear moon to the desnaon point at the current traverse rate (or
slower if the mill does not go that fast). It is expected that cung won’t take place when a G00
command is execung. It is an error if all axis words are omied. The axis words are oponal, except
that at least one must be used. The G00 is oponal if the current moon mode is G00.
(...continued)
