Chapter 11
228
UM10350_PCNC770_Manual_0916A
Diagrams and Parts List
Tools and Related Items
PN Description
31302 Manual Oil Pump
31221 Automatic Oil Pump
31386 Machine Way Oil
35355 AC Bearing Service Kit – Complete tool kit used to adjust pre-load on ball screw AC bearings.
35427
PCNC 770 Printed Manual – Replace your old manual with the latest version; three-hole punched. Manual
PDF can also be downloaded at www.tormach.com
30572
Touch-up Paint – Dark Gray 2.5 oz matching the lower section of the stand. Original paint is oil based,
touch-up is latex.
30571
Touch-up Paint – Light Gray 2.5 oz matching the PCNC 770 and the upper section of the stand. Original
paint is oil based, touch-up is latex.
30624 DIN Connector – 5 pin. This is a plug that will t in the accessory jack on the front of the electrical cabinet.
30482
CPC Connector – Reverse Gender. This is the plug that is on the end of the 4th axis and connects to the
side of the PCNC cabinet.
31668 Machine Stand Door Latch Center
31669 Machine Stand Door Latch Side
30725 Coolant Hose, armored
32746 Coolant Pump, OEM replacement
33216 Coolant Pump, upgrade, dual voltage, 120/220 VAC
31105 Coolant Hose Mount Bracket
32833 Segmented Spray Hose (blue/orange) – upgraded
32832 Coolant Mount Coupling
31366 Coolant Refractometer
31667 Coolant Tank (tank only)
31192
PCNC 770 Coolant Kit (includes 30725, 31382, 31105, 30726, 31667, rear splash guards, and table splash
guards)
33215 Coolant Hose Accessory Kit
31333 PCNC 770 Moving Kit
32436 Power Drawbar Kit for 770
31728 Power Drawbar Foot Pedal
31101 Spindle Load Meter Kit
