ServicingtheFrontAxleDriveMotor(MachineSerialNumber

above316000000)

g224914

Figure91

1.Retainingring6.Thrustbearing11.Valveplate

2.Spacer7.Splineddriveshaft12.O-ring

3.Washer8.Housingassembly13.Backplateassembly

4.Retainingring(2each)9.Camplateinsert

14.Plugassembly

5.Bearingrace(2each)

10.Rotatingkitassembly

15.Bolt(6each)

Note:Forthehydraulicmotorrepairprocedures;refertotheEatonMotors74111

and74118FixedAxialPistonMotorRepairManual.

IMPORTANT

Ifahydraulicmotorfails;refertotheTractionCircuitComponent

Failure(page5–7)forinformationregardingtheimportanceof

removingcontaminationfromthetractioncircuit.

Groundsmaster

3280-D/3320

Page5–109

HydraulicSystem:ServiceandRepairs

05138SLRevB
