DifferentialGearAssembly(4-WheelDriveAxle)

Thefollowingproceduresassumethe4-wheeldriverearaxleassemblyhas

beenremovedfromthemachine.

RemovingtheDifferentialGearAssembly(4-WheelDriveAxle)

1.Removethebevelgearcase/axlecaseassemblies;refertoBevelGearCase

andAxleCase(4-WheelDriveAxle)(page8–49).

IMPORTANT

Donotinterchangetherightandleftdifferentialshaftsassemblies.

2.Forassemblypurposes,markthedifferentialshaftassemblies.Pullthe

differentialshaftassembliesfromtheaxlesupport.

g226493

Figure275

1.Casescrew4.O-ring7.Axlesupport(left)

2.O-ring

5.Piniongearassembly

3.Differentialgearassembly6.Axlesupport(right)

3.Removetheinputshaft/piniongearassembly,shims,andO-ringfromthe

axlesupport(Figure275).

4.Removetheaxlesupportcasescrews.Separatetheaxlesupporthalves

andremovetheO-ring.

5.Removethedifferentialgearassembly,bearings,andadjustingshimsfrom

theaxlecase.

DriveAxles:ServiceandRepairs

Page8–64

Groundsmaster

3280-D/3320

05138SLRevB
