BevelGearCaseandAxleCase(4-WheelDriveAxle)

Thefollowingproceduresassumethe4-wheeldriverearaxleassemblyhas

beenremovedfromthemachine.

RemovingtheBevelGearCaseandAxleCase(4-WheelDriveAxle)

g226459

Figure256

1.Mountingscrew

3.Bevelgearcase/axlecase

assembly

5.Locknut

2.O-ring

4.Lockwasher6.Axlesupport

1.Removethemountingscrews,nuts,andlockwashers,andremovethebevel

gearcase/axlecaseassemblyandO-ringfromtheaxlesupport(Figure256).

2.Markbothrightandleftbevelgearcase/axlecaseassemblies.

IMPORTANT

Donotinterchangetherightandleftbevelgearcase/axlecase

assemblies.

g226487

Figure257

1.Axlecase3.Mountingscrew

2.O-ring

4.Axlecoverassembly

3.Removetheaxlecovermountingscrews,andremovetheaxlecoverfrom

theaxlecaseasanassembly(Figure257).

Groundsmaster

3280-D/3320

Page8–49

DriveAxles:ServiceandRepairs

05138SLRevB
