Toro 30403 Service Manual

Specications
Groundsmaster3280-D
g243928
Figure20
1.Startermotor3.Engineoillter
5.Fuelinjectionpump
2.Alternator4.Flywheel
6.Enginecoolingfan
Engine-Groundsmaster3280-D
ItemDescription
Make/Designation
KubotaD1105:4-cycle,3cylinderwatercooled
diesel.EPATier4compliant.
Bore
78mm(3.07inches)
Stroke78.4mm(3.09inches)
Totaldisplacement
1123cm
3
(68.53in
3
)
Firingorder
1(front)-2-3
CompressionRatio
22:1
Fuel
DieselorBiodieselfuel(uptoB20)
Fueltankcapacity
42.8L(11.3USgallons)
FuelinjectionpumpBoschMDtypemini
Fuelinjectornozzle
Mininozzle(DNOPD)
GovernorCentrifugalmechanical
Lowidle(noload)
1,500to1,650rpm
Highidle(noload)
3,100to3,250rpm
Engineoil
APIclassicationCH−4,CI−4,orhigher
Engine-oilviscosity
RefertotheOperator’sManual
Crankcase-oilcapacity3.8L(4.0USqt)
DieselEngine:Specications
Page4–2
Groundsmaster
®
3280-D/3320
05138SLRevB
