TestingtheElectricalComponents

Foraccurateresistanceand/orcontinuitychecks,electricallydisconnectthe

componentbeingtestedfromthecircuit(e.g.,unplugthekeyswitchconnector

beforedoingacontinuitycheckoftheswitch).

Note:Electricaltroubleshootingofany12Voltpowerconnectioncanbe

performedthroughvoltagedroptestswithoutdisconnectingthecomponent.

Note:RefertotheKubotaWorkshopManual:05SeriesEngine(Groundsmaster

3280-D)orBriggsandStratton/DaihatsuEngineRepairManual(Groundsmaster

3320)foradditionalelectricalcomponentrepairinformation.

IMPORTANT

Whentestingtheelectricalcomponentsforcontinuitywitha

multimeter(ohmssetting),ensurethatyoudisconnectthepowerto

thecircuit.

FusibleLinkHarness

g225177

Figure119

1.Fusiblelinkharness

2.Startermotor

3.Positivebatterycable

ElectricalSystem:TestingtheElectricalComponents

Page6–20

Groundsmaster

3280-D/3320

05138SLRevB
