ParkingBrakeSwitch

g227534

Figure117

1.Steeringtowercover3.Phillips-headscrew(2each)

2.Parkingbrakeknob

4.Phillips-headscrew(6each)

Theswitchusedfortheparkingbrakeisanormallyopenswitch.Theswitch

closeswhentheparkingbrakeisdisengaged.Theparkingbrakeswitchis

locatedunderthesteeringtowercover(Figure117).Thesensingplateforthe

parkingbrakeswitchistheparkingbrakerodtab(Figure118).

AdjustingtheParkingBrakeSwitch

g226937

Figure118

1.Parkingbrakeswitch

3.Switchplunger

2.T ab(parkingbrakerod)

Whentheparkingbrakeisset,thecompressedlengthoftheswitchplunger

shouldbe0.38to1.14mm(0.015to0.045inch)(Figure118).

Note:Thisisthedistancebetweentheparkingbrakerodtabandtheswitch

plungerhousing.

Ifthegapisincorrect,adjusttheparkingbrakeswitch;refertoAdjustingthe

Parking-Brake-InterlockSwitchintheTractionUnitOperator’sManual.

Groundsmaster

3280-D/3320

Page6–19

ElectricalSystem:Adjustments

05138SLRevB
