PushingorTowingtheTractionUnit

IMPORTANT

Iftowinglimitsareexceeded,severedamagetothehydraulicpump

mayoccur.

g230813

Figure35

1.Checkvalvelocation

g224908

Figure36

1.Hydraulicpump(forModels30344and

30345)

2.Bypassvalve

Ifitbecomesnecessarytotoworpushthemachine,toworpushataspeed

below4.8km/h(3mph),andforaveryshortdistance.Ifyoumustmovethe

machineaconsiderabledistance(morethanafewfeet),transportitonatruck

ortrailer.Thetransmissionisequippedwithtwocheckvalvesthatneedtobe

pressedfortowingorpushing(Figure35).Thehydraulicpumpisequippedwith

abypassvalvethatneedstobeloosenedfortowingorpushing(Figure36).

RefertotheTractionUnitOperator'sManualfortowingprocedures.

Groundsmaster

3280-D/3320

Page5–5

HydraulicSystem:GeneralInformation

05138SLRevB
